GOC Conveyor Belt

Constant opening modular Conveyor belt formed by eye links mounted in pairs and interconnected by straight bars with side chains.

Like the GO Conveyor belt, it is easy to clean and sanitize as well as to install and maintain.

Technical Data

Width: from 100 to 4000 mm
Mesh Pitch: from 2,4×25,4 mm to 6×50,8 mm
Spiral Wire: from 1,2 to 3 mm
Ø Crossbar: from 3 mm to 10 mm
Chain Pitch: from 1" (25,4 mm) to 2" (50,8 mm)

Materials

AISI 304
AISI 316

Applications

This belt is mainly used in the food sector and as a filter system.

Cooling
Dehydration
Desiccation
Surface treatment
Tunnel washing machines

GOC wire mesh belt nastro trasportatore
Technical Sheet
Brochure WBT

Accessories for this conveyor belt

Side plates

Drivers / Lifters

Available Edges

Welded edges with side plates

Welded edges
